Quark 3″

The micro revolution is here and it’s awesome!

The Atto Quark is a ‘stretched -X’ 3″ frame designed around the new wave of micro components for a super light and strong racing build that is perfect for the track.

The stretched X design is favoured by many top pilots for several reasons. It offers super agile cornering and stable pitch control at high speeds as well as providing a clean air flow for the rear props. It’s perfect for high speed tracks and the with the right build can easily rival 4 and 5″ quads for speed whilst out cornering them too.

The Quark is supplied with both stainless steel Torx and steel hex frame bolts, colour matched FC mounting hardware, 25mm and 30mm standoffs plus a carbon prop spanner.

Atto Quark Frame-7Atto Quark Frame-2

The Quark is was developed specifically for a 20mm flight controller and the Atto 20mm PDB is included with the frame. This allows you to build for any voltage while the smaller components allow a thinner frame and lower standoffs to be used, reducing drag and weight whilst increasing strength.

The Quark accepts any motors from 1103 to 1707. We recommend a 1408 motor paired with 20A ESCS. Most small ESCS will fit on the the arms if required. There is no SMA  mounting option as the frame is intended to be used with a dipole or whip antenna. See the Quark build log for details.

Atto Quark frame kit includes:

  • 3mm base plate
  • 2mm top plate
  • 3 x 25mm aluminium standoffs
  • 3 x 30mm aluminium standoffs
  • 4x 3mm aluminium standoffs
  • 6 x 6mm Stainless steel M3 torx bolts
  • 6 x 6mm Steel M3 hex bolts
  • 4 x 12mm Alloy M3 bolts
  • M5 Spanner / keyring

Bare frame weight with stainless torx hardware – 33g

Bare frame weight with stainless torx hardware, alloy FC hardware plus PDB – 38.4g
