Photon 5-6″

True X or Stretched? Lightweight or super strong? Full size or micro? What if one frame could do it all without compromises?

Introducing the Atto Photon. A unique frame with a split personalty.

Atto Photon Frame-46Atto Photon Frame-5Atto Photon Frame-3The Photon can be built as a 218mm X frame for 5-5.5” props or a 258mm stretched X for 5-6” props. Options for single or double base plates with room for 30.5mm and 20mm FC stacks are included. The innovative top plate design accepts a wide range of 3D printed mounts for all types of cameras and antennas with designs available to download and modify for free.

Atto Photon Frame-23Atto Photon Frame-36The 5mm thick boomerang style arms can be secured with just 2 bolts for lightweight builds or 4 bolts for added strength. The frame kit is supplied with M3 hex and stainless steel torx hardware as well as both 25mm and 30mm standoffs giving you a huge range of build options. However you choose to put your Photon together, each configuration has been tested and refined to make the stiffest most responsive frame we can. Every bit as strong as a unibody design but infinitely more versatile.

Atto Photon frame kit includes

  • 2 x 5mm Photon Arms
  • 3mm Base plate
  • 2mm Mini top plate
  • 2mm Micro top plate
  • 2mm X plate
  • 3mm Locking disc
  • Atto 20mm PDB
  • 4 x 30mm M3 Standoffs
  • 4 x 25mm M3 Standoffs
  • 4 x 3mm M3 Standoffs
  • 4 x 16mm Stainless M3 Torx bolts
  • 4 x 12mm Stainless M3 Torx bolts
  • 4 x 10mm Stainless M3 Torx bolts
  • 8 x 6mm Stainless M3 Torx bolts
  • 4 x 12mm Steel M3 Hex bolts
  • 8 x 6mm Steel M3 Hex bolts
  • 4 x 16mm Anodised Alloy M3 bolts
  • 4 x 12mm Anodised Alloy M3 bolts
  • 4 x M3 Steel Nylon nuts
  • 3mm Carbon prop spanner
