The DC130 is our smallest frame designed for 3″ props and it is tiny but tough. The 3mm dead cat configuration frame moves the yaw point forward for precision turns and can be built with a choice of top plates to accommodate full size or micro components.
This frame offers more camera protection than the 136-R and is ideal for fast acro flying.
Choose to run a full size flight controller and 4in1 ESC or micro flight controller with ESC’s on the arms. The shorter rear arms add strength and reduce weight. This is an advanced build if using a standard FC, the rear props will hang over the corners of any 30.5mm FC. If needed you can use the an Atto motor riser set to add some clearance.
A satellite RX can fit inside the frame with 35mm standoffs. For larger receivers, use 40mm standoffs or add the piggyback plate for extra space up top.
DC130 kit includes:
- 3mm DC130 frame
- 1.5mm Nano plate
- 1.5mm Micro plates
- 1.5mm Piggyback plate
- 35mm alloy main standoffs
- 10mm alloy piggyback standoffs
- Titanium M3 bolts
- Alloy M3 FC bolts
- Alloy FC spacers
- 3mm motor risers
- Alloy M5 motor nuts
- XT-30 connector
- M5 Spanner / keyring
Bare frame weight with 1.5mm nano plate, 35mm alloy standoffs, titanium bolts – 33.9g
Lightweight – Pico BLX flight controller with stackable VTX, LittleBee 4in1 20A ESC, DYS 1104 4000kv motors, 3×2.5×2 props, DSMX satellite or micro RX
Frightening – F3 30.5mm flight controller, VTX with side mounted SMA or pigtail, small 20A ESC, 1306 4000kv motors, 3x3x4 props, DSMX satellite or micro RX inside the frame, Full size RX using piggyback plate.
